Carbon Auto Backwash Filter Commercial 9510 3.0 CF

Carbon Auto Backwash Filter Commercial 9510 3.0 CF

Frequently Bought Together

Processing...
Code: CF003850
$1,975.00 $3,411.00 List Price

In Stock!

Overview

Commercial Activated Carbon Backwash Filters 1-1/2" In-Out Fittings

  • Excellent for use in dechlorinating water and removing many tastes and odors
  • Higher flows, lower pressure drop.
  • Removes chloramines with the optional Catalytic Carbon upgrade
  • Much longer life and higher flow rates than carbon filter cartridges.

    • Read Full Description

    • Description
    • Specs
    • Warranty
    • Documents

    Commercial Activated Carbon Backwash Filters 1-1/2" In-Out Fittings



  • Excellent for use in dechlorinating water and removing many tastes and odors
  • Higher flows, lower pressure drop.
  • Removes chloramines with the optional Catalytic Carbon upgrade
  • Much longer life and higher flow rates than carbon filter cartridges.
  • Unlike carbon cartridges which can trap sediment and dirt, these systems automatically backwash out trapped sediment, alleviating pressure drop.
  • certified, one piece, seamless polyester filter tank for long life
  • Heavy-Duty 9510 NSF certified backwash control valve is completely Water Proof
  • Higher Flow Rates for large residential and commercial applications
  • Meter immediate, meter delayed, meter with day over-ride and calendar clock modes all included for maximum flexibility and regeneration
  • All activated carbon filter backwash systems include filter media, tank, & backwash control valve
  • Excellent for use in dechlorinating water and removing many tastes and odors
  • High activity granular activated carbon is manufactured by steam activation from select coconut shell charcoal.
  • Removes low molecular weight organic compounds and their chlorinated by-products such as chloroform and other trihalomethanes (THM's).
  • Removes chloramines with the optional Catalytic Carbon upgrade
  • Iodine Rating: minimum 1000 mg/g
  • Our activated carbon has maximum hardness and is well suited for backwash applications.
  • Removes sediment as well as filtering out tastes and odors
  • Easy to service: little or no maintenance. Carbon is easy to dump out and change after many years.
  • No chemicals or salt required.

    Includes:

  • 9510 Commercial Control valve 12VDC. Uses less than 20 watts of power.
  • Voltage 110v-230V Power Adapter.
  • 1-1/2" NPT Pipe size: 1" in - out - drain fittings, easy to adapt to 3/4" pipe if needed.
  • Bypass Valve
  • Our Coconut Shell Activated Carbon is Certified
  • certified filter tank
  • See Install Video Here




    • Sizing Guide

    ModelNumber of Bathrooms in HomePeak Flow RateBackwash Flow RatePipe SizeDimensions
    2.0 CF
    		2 - 3
    		12 GPM
    		7 GPM
    		1.5"12" X 67"
    2.5 CF
    		2 - 3
    		14 GPM
    		10 GPM
    		1.5"
    		13" X 68"
    3.0 CF
    		2 - 4
    		16 GPM
    		12 GPM
    		1.5"
    		14" X 80"
    4.0 CF
    		2 - 5
    		18 GPM
    		12 GPM
    		1.5"
    		16" X 80"
    5.0 CF2 - 520 GPM15 GPM1.5"
    		18" X 80"

    Higher flow rates are possible if contact time is not an issue.

    For example to remove chlorine tastes and odors on city water, 5 to 8 gallons per minute per cubic foot of carbon works fine depending on chlorine levels.

    However if you are trying to remove a particular chemical such as PFOS or benzene, lower flow rates with longer contact time are recommended.

    Add KDF cubes to extend life of carbon and achieve higher flow rates.

    Warranty:

  • 5 year Warranty on the filter tanks. All tanks and valves are NSF Certified & top quality.
  • 5 Year Warranty on the control valve.
  • See our Return Policy Here

    Manufacturer: CWS

    Manufacturer #: CF003850

    Download Installation Guide
